AP360I-WR Wi-Fi 6 Outdoor Access Point --- Built For Harsh Environments And High-Density Connectivity
Ürün ayrıntıları:
| Marka adı: | Extreme |
| Model numarası: | AP360I-WR |
| Belge: | ap360-data-sheet.pdf |
Ödeme & teslimat koşulları:
| Min sipariş miktarı: | 1 adet |
|---|---|
| Fiyat: | Negotiate |
| Ambalaj bilgileri: | Dıştaki kutu |
| Teslim süresi: | Envantere dayalı |
| Ödeme koşulları: | T/T |
| Yetenek temini: | Proje/Parti ile Tedarik |
|
Detay Bilgi |
|||
| Durum: | Yeni ve orijinal | Kullanılabilirlik: | Stoklamak |
|---|---|---|---|
| Desteklenen frekans: | 5GHz ve 2.4GHz | Tip: | Çift radyo |
| İletim Standardı: | 802.11ax | Garanti süresi: | 1 Yıl |
| Ağırlık: | 1.0Kg | Boyutlar: | 190mm x 145mm x 50mm |
| Vurgulamak: | Wi-Fi 6 outdoor access point,harsh environment wireless AP,high-density connectivity access point |
||
Ürün Açıklaması
ExtremeWireless AP360I-WR: Outdoor Wi-Fi 6 Tri-Radio Access Point for EMEA
Reliable, Secure Outdoor Connectivity for EMEA
The ExtremeWireless AP360I-WR delivers enterprise-grade Wi-Fi 6 performance in a rugged, outdoor-optimized design. It transcends the role of a basic network card by integrating a full tri-radio system, including a dedicated security sensor for 24/7 network protection. Certified for the EMEA region and built to IP67 standards, it withstands harsh weather, offering a resilient wireless foundation that outperforms standard indoor nic card solutions or generic mq9700-type devices in challenging environments.
1. Product Overview
The ExtremeWireless AP360I-WR is a specific regional variant (EMEA, Rest of World) of the high-performance AP360 series. This tri-radio outdoor access point leverages Wi-Fi 6 (802.11ax) technology to provide high-speed, efficient wireless coverage. With integrated antennas and a focus on high-density performance, it is the ideal solution for extending secure, reliable Wi-Fi to outdoor areas across Europe, the Middle East, and Africa.
2. Key Characteristics
- Regional Compliance (EMEA/WR): Certified for operation across Europe, the Middle East, Africa, and Rest of World markets.
- Tri-Radio Architecture: Combines high-speed client serving radios with a dedicated, full-time dual-band sensor for continuous security and RF monitoring.
- Wi-Fi 6 Efficiency: Supports OFDMA and MU-MIMO to serve multiple clients simultaneously, reducing latency in crowded areas.
- Rugged Outdoor Design: IP67 enclosure rating protects against dust and water ingress, ensuring operation in varied climates.
- Integrated Security: Features WPA3 support and a stateful firewall. The dedicated sensor provides proactive threat detection, a critical layer beyond standard nic card security features.
- Simplified Deployment: Integrated antennas eliminate the need for separate antenna sourcing and installation.
3. Core Technologies & Standards
- Wireless Standards: 802.11ax (Wi-Fi 6), backward compatible with 802.11a/b/g/n/ac
- Radio Configuration: 4x4:4 in 5 GHz, 2x2:2 in 2.4 GHz, plus 2x2:2 Dual-Band Sensor
- Key Wi-Fi 6 Features: Uplink/Downlink OFDMA, MU-MIMO, 1024-QAM modulation, BSS Coloring
- Security Suite: WPA3, WPA2, 802.1X/AES, dedicated sensor for WIPS (Wireless Intrusion Prevention)
- Power & Connectivity: 802.3at PoE+ powered, featuring a 2.5GbE uplink port for future-proof backhaul.
4. Working Principle
At its core, the AP360I-WR functions as an intelligent wireless hub. The primary client-serving radios use advanced Wi-Fi 6 scheduling (OFDMA) to communicate efficiently with dozens of devices at once. Parallel to this, the independent sensor radio continuously scans the 2.4 GHz and 5 GHz spectrums, creating a real-time map of the RF environment. This allows it to identify interference, rogue devices, and potential security breaches without consuming resources from the data path. This dual-purpose design ensures that performance for connected users—whether they're on a laptop, phone, or specialized device with a mq9700 network card—is never compromised by security overhead.
5. Application Scenarios
- University & School Campuses: Covering courtyards, sports fields, and outdoor study areas across EMEA.
- Hospitality & Resort Venues: Providing guest Wi-Fi at poolside, in gardens, and across expansive hotel grounds.
- Public Sector & Municipalities: Deploying in city centers, public parks, and transportation waiting areas.
- Retail & Outdoor Shopping: Enabling connectivity in open-air markets, outlet villages, and parking lots.
- Industrial Perimeters: Connecting sensors, cameras, and handheld terminals in yard management and logistics zones.
6. Technical Specifications: AP360I-WR
| Attribute Category | Specification |
|---|---|
| Product Model & Domain | AP360I-WR (EMEA, Rest of World) |
| Wi-Fi Standard & Data Rates | 802.11ax (Wi-Fi 6). Aggregate rates up to 4.8 Gbps (5 GHz) + 2.4 Gbps (2.4 GHz) |
| Radio Design | Tri-Radio: 5GHz 4x4:4 (Client), 2.4GHz 2x2:2 (Client), 2x2:2 Dual-Band (Full-time Sensor) |
| Antennas | Integrated omnidirectional antennas (Internal design) |
| Network Interfaces | 1x 2.5GbE RJ-45 (PoE+ in), 1x 1GbE RJ-45 |
| Power Supply | 802.3at PoE+ (Typical 15.23W), compatible with 802.3af |
| Physical Dimensions & Weight | 10" x 7.5" x 2.5" (260mm x 192mm x 65mm) / Approx. 3.7 lbs (1.7 kg) |
| Environmental Robustness | IP67 Rating, Operating Temperature: -40°C to +60°C, Wind Gust Resistance: 165 mph |
| Core Security Features | WPA3, Dedicated Security Sensor Radio, L2-L7 Stateful Firewall |
| Additional Features | Integrated GPS, Bluetooth Low Energy (BLE), Cellular Coexistence Filter (CCF) |
7. Competitive Advantages
- EMEA-Optimized Compliance: Comes pre-certified for radio regulations across EMEA and RoW regions, simplifying procurement and deployment logistics.
- Performance-Security Balance: The dedicated sensor ensures robust security scrutiny without taxing the data-handling capacity of the main radios, a clear advantage over systems where security functions compete for network card resources.
- All-in-One Rugged Design: The integrated antenna model (AP360I) offers a clean, vandal-resistant installation with no external components, ideal for public spaces.
- Future-Proofed Uplink: The 2.5GbE port ensures the access point will not become a bottleneck as internet speeds and internal network demands increase, protecting your investment better than a traditional 1GbE nic card interface.
8. Service & Support
The AP360I-WR is backed by Extreme Networks' global support infrastructure. It includes a standard 1-year manufacturer's warranty. Customers have access to comprehensive online resources, firmware updates, and technical support channels specific to the EMEA region. For enterprise deployments, optional premium support plans, advance hardware replacement (RMA), and professional design services are available to ensure seamless integration and long-term reliability.
9. Frequently Asked Questions
Q: What does "-WR" in the model name signify?
A: The "-WR" suffix indicates the "World Radio" or "Rest of World" regulatory domain. This model (AP360I-WR) is certified for use in Europe, the Middle East, Africa, and other regions not covered by specific US (FCC) or Canada (IC) variants.
Q: Can the dedicated sensor be disabled or repurposed as a client radio?
A: No. The sensor radio is a fixed-function component designed specifically for continuous security and RF monitoring. This dedicated hardware approach provides more reliable and comprehensive protection than software-based monitoring on a shared nic card. The client serving radios are separately optimized for high-throughput data.
Q: Is this AP suitable for harsh industrial environments?
A: Yes. With its IP67 rating, extended temperature tolerance (-40°C to +60°C), and corrosion-resistant materials, the AP360I-WR is built to withstand demanding conditions like those found in manufacturing plants, ports, and mining operations, far exceeding the environmental specs of a typical indoor mq9700 component.
Q: What management options are available?
A: It can be managed via ExtremeCloud™ IQ for cloud-based simplicity and scalability, or by on-premises Extreme Networks wireless controllers (e.g., VX or NX series) for customers requiring local management.
10. Installation & Usage Notes
- Regulatory Compliance: The AP360I-WR is certified for EMEA/RoW. It must not be deployed in regions (like the USA or Canada) requiring different radio certifications (e.g., FCC, IC).
- Power Requirements: For full feature operation, use an 802.3at (PoE+) compliant switch or midspan injector. Operation on 802.3af may limit performance or disable some radios.
- Environmental Sealing: While the unit is IP67 rated, ensure the Ethernet cable and connector are properly weatherproofed using suitable glands or enclosure kits to maintain the integrity of the installation.
- Mounting & Grounding: Use the recommended mounting kits for pole or wall installation. Follow local electrical codes for proper grounding, especially in areas prone to lightning strikes.
- Configuration Best Practice: Leverage the dedicated sensor's capabilities by enabling Wireless Intrusion Prevention System (WIPS) policies in the management platform for optimal security, a feature that utilizes the AP's hardware beyond a standard network card function.
