NVIDIA ConnectX-4 Lx EN MCX4121A-XCAT – Dual-Port 10GbE SFP28 Adapter Card with RoCE Virtualization Offloads
Ürün ayrıntıları:
| Marka adı: | Mellanox |
| Model numarası: | MCX4121A-XCAT |
| Belge: | connectx-4-lx-en-card.pdf |
Ödeme & teslimat koşulları:
| Min sipariş miktarı: | 1 adet |
|---|---|
| Fiyat: | Negotiate |
| Ambalaj bilgileri: | Dıştaki kutu |
| Teslim süresi: | Envantere dayalı |
| Ödeme koşulları: | T/T |
| Yetenek temini: | Proje/Parti ile Tedarik |
|
Detay Bilgi |
|||
| Ürün durumu: | Stoklamak | Başvuru: | Sunucu |
|---|---|---|---|
| Durum: | Yeni ve orijinal | Tip: | kablolu |
| Maksimum Hız: | 25GB/S | İsim: | MCX4121A-XCAT MELLANOX Ağ Kartı 25GBPS SFP28 QSFP28 Sunucu için |
Ürün Açıklaması
Dual-port SFP28 10GbE Ethernet adapter card — delivering low latency, RDMA over Converged Ethernet (RoCE), and hardware-based virtualization offloads. Ideal for cloud, Web 2.0, database, and storage platforms requiring cost-effective 10GbE connectivity with advanced acceleration.
The NVIDIA ConnectX-4 Lx EN MCX4121A-XCAT is a dual-port 10GbE Ethernet adapter card designed for data centers that demand high throughput, sub-microsecond latency, and efficient server utilization. Built on the proven ConnectX-4 Lx architecture, this adapter supports 10GbE and 1GbE speeds, making it a flexible solution for enterprise and cloud environments. It offloads transport operations, overlay network encapsulation (VXLAN, NVGRE), and provides hardware-based I/O virtualization (SR-IOV). The MCX4121A-XCAT includes RoCE (RDMA over Converged Ethernet) for low-latency memory access, PeerDirect for GPU communication acceleration, and comprehensive management interfaces including NC-SI for BMC integration.
Two SFP28 ports supporting 10GbE and 1GbE speeds. Interoperable with standard Ethernet switches.
Low-latency, high-performance RDMA services over Layer 2 and Layer 3 networks.
SR-IOV supports up to 256 Virtual Functions (VFs) and 8 Physical Functions per port for VM isolation.
Hardware encapsulation/de-encapsulation for VXLAN, NVGRE, and GENEVE – preserving native performance.
TCP/UDP stateless offloads, LSO/LRO, checksum offload, RSS/TSS, and intelligent interrupt coalescence.
NC-SI over MCTP (SMBus/PCIe) for BMC integration, remote boot over iSCSI, PXE, and UEFI.
The ConnectX-4 Lx EN ASIC delivers 75 million packets per second message rate and sub-microsecond latency. Key innovations include:
- PeerDirect (GPUDirect) – Eliminates unnecessary PCIe data copies between GPU and CPU, accelerating HPC and AI workloads.
- Extended Reliable Connected (XRC) & Dynamically Connected Transport (DCT) – Scales RDMA to tens of thousands of nodes.
- On-Demand Paging (ODP) – Registration-free RDMA memory access, simplifying application development.
- Advanced Congestion Control – IEEE 802.1Qau (QCN), ETS, PFC for lossless RoCE fabrics.
High-density virtualization hosts with 10GbE connectivity, requiring low overhead and high packet rates.
iSCSI, NVMe-oF, and SMB Direct over RoCE for high-performance block/file access.
Low-latency RDMA accelerates distributed databases (e.g., Cassandra, MongoDB) and big data frameworks.
PeerDirect enables direct GPU-to-GPU communication without CPU involvement, ideal for AI training.
The MCX4121A-XCAT is compatible with a wide range of operating systems: RHEL/CentOS, Ubuntu, Windows Server, FreeBSD, VMware ESXi, and Citrix XenServer. It supports standard 10GbE SFP+ optics, passive DAC cables up to 5m, and active optical cables. The adapter integrates seamlessly with NVIDIA Spectrum switches and any standards-based 10GbE/25GbE infrastructure. Software support includes OFED (OpenFabrics Enterprise Distribution) and WinOF-2 for Windows.
| Category | Specification |
|---|---|
| Model | MCX4121A-XCAT |
| Form Factor | Low-profile PCIe add-in card (14.2cm x 6.9cm without bracket). Ships with tall bracket mounted, short bracket included. |
| Ports | 2x SFP28 (10GbE / 1GbE) |
| Supported Speeds | 10GbE, 1GbE |
| Host Interface | PCIe 3.0 x8 (compatible with x16, x4, x2, x1; auto-negotiated) |
| Message Rate | 75 million packets per second (Mpps) |
| Latency | Sub-microsecond (typical) |
| Virtualization | SR-IOV: up to 256 Virtual Functions, 8 Physical Functions per port |
| RoCE Support | Yes – RDMA over Converged Ethernet (RoCE) |
| Overlay Offloads | VXLAN, NVGRE, GENEVE hardware encapsulation/de-encapsulation |
| CPU Offloads | TCP/UDP checksum offload, LSO/LRO, RSS, TSS, VLAN insertion/stripping |
| Management Interfaces | NC-SI over MCTP (SMBus/PCIe), BMC interface, SDN eSwitch management, SPI flash, JTAG |
| Remote Boot | PXE, UEFI, iSCSI remote boot |
| Power Consumption | Not publicly specified – please confirm before ordering |
| Operating Temperature | 0°C to 55°C (typical) |
| Standards | IEEE 802.3ae (10GbE), 802.3az EEE, 802.1Qbb PFC, 802.1Qaz ETS, 1588v2, PCIe Gen 3.0 |
| RoHS | Compliant |
| OPN (Ordering Part Number) | Ports | Max Speed | Interface | Key Feature |
|---|---|---|---|---|
| MCX4121A-XCAT | 2 | 10GbE | SFP28 | Dual-port, Host Management, UEFI enabled |
| MCX4111A-XCAT | 1 | 10GbE | SFP28 | Single-port, low profile |
| MCX4121A-ACAT | 2 | 25GbE | SFP28 | Dual-port 25GbE |
| MCX4131A-BCAT | 1 | 40GbE | QSFP28 | 40GbE single-port |
| MCX4131A-GCAT | 1 | 50GbE | QSFP28 | 50GbE single-port |
Delivers line-rate throughput and low latency for virtualized and bare-metal servers.
Works with standard Linux distributions, Windows, and VMware – no vendor lock-in.
VXLAN/NVGRE offloads protect CPU resources as overlay networks become ubiquitous.
Hong Kong Starsurge offers competitive pricing, warranty support, and fast worldwide delivery.
Hong Kong Starsurge provides end-to-end support for NVIDIA/Mellanox adapters, including compatibility verification, firmware updates, and technical troubleshooting. Standard warranty aligns with NVIDIA's limited hardware warranty (1 year return-and-repair). Extended support options are available upon request. Our team can assist with driver installation, performance tuning, and integration into existing server environments.
| Category | Supported Options |
|---|---|
| Operating Systems | RHEL/CentOS, Ubuntu, Windows Server 2016/2019/2022, FreeBSD, VMware ESXi 6.5+, Citrix XenServer |
| Switches | NVIDIA Spectrum series, Cisco Nexus, Arista, Juniper, any standards-based 10GbE/25GbE switch |
| Cables and Optics | SFP+ passive DAC (up to 5m), SFP+ active optical cable, 10GBASE-SR (850nm), 10GBASE-LR (1310nm) |
| Management Protocols | NC-SI, MCTP over PCIe/SMBus, PLDM for monitoring and firmware update |
- Confirm server has an available PCIe x8 (or larger) slot – Gen 3.0 or higher.
- Determine required cable type: passive DAC, active optical, or optical transceivers for your distance.
- Verify operating system driver availability from NVIDIA/Mellanox official site.
- Check if your switch supports 10GbE SFP+ modules (most modern switches do).
- For BMC integration, ensure your motherboard supports NC-SI over SMBus or PCIe.
Dual-port 25GbE adapter for higher bandwidth requirements.
48x 25GbE + 12x 100GbE top-of-rack switch for leaf/spine fabrics.
Passive copper direct-attach cables for 10GbE/25GbE connections.
